Operating system

Operating system

Linux 3.10.73

Booting time

< 8 s

Language

English/Russian

Video

Video input

1x digital camera for 1080p/720p/360p recording, available for external camera

Video output

2” LCD screen

Recording resolution

1920x1080/1280x720/640x360p

Frame rate

30fps at 1080p

Record mode

Record audio and video at the same time

Compression

H.264 (high-profile up to level 4.1)

Audio

Audio input

1x Mic input, support intercom connection with USB

Compression

PMC

Audio record

Supports audio recording

Video process

Live video resolution

1920x1080/1280x720/640x360

Photograph

1920x1080-8640x4752p

Snap

Supports snapping during recording (photo resolution base in recording resolution)

Storage

Built in 16GB TF card (available for 16-128GB)

Light source

Flash light

To increase brightness when you are recording or taking a photo

Laser

Fix the view when you record

IR

Up to 10 meters with visible shape image at night

Two way radio

Talk back

Supports two way radio between different devices (only for 4G/3G device)

Talk back in platform

Supports two way radio between device and platform (only for 4G/3G device)

Lens

Lens’s angle

>125°

Alarm

Alarm input

Supports alarm input and the alarm can be show in platform

Interface

USB

1x USB, for charging, communication with PC, upgrade OS, connect external camera

Network

Protocol

TCP/IP

3G/4G

Optional, built in 3G/4G module (LTE FDD/LTE TDD/WCDMA/TD-SCDMA/GSM/CDMA EVDO/CDMA 1x. Note: this could be different with different module.)

wifi

Optional, supports Wi-Fi connection and AP

GPS

GPS

Optional module for BDS/GPS/GLONASS, to record location and speed

Firmware

OSD

Display and record time, license ID, officer ID, location, speed

Overwrite

Supported

Play back

Support play back, file listed by time and alarm

Play speed

Support from 1/128 to 128

Pre-recording/post-recording

Maximum 20S pre-recording and post-recording

Dewarp

Supports dewarp to make the picture more accurate and realistic

Safe mode

Need password to enter setting or playback in safe mode

Record encryption

Supports record encryption, encrypted video can be played in special player

Log

Record power on/off, setting change, start record, alarm etc

Software

Player

Player software, play multiple cameras together, can also play the encrypted file

CMSV6

Used for 4G/3G model only, support live view/live tracking/historical track

Upgrade

Firmware maintain

Firmware can be upgrade though USB

Working condition

Temperature

 -40 to 60℃

Humidity

 40 to 80%

Other

Time

Synchronize with GPS, internet, PC

Dual bit stream

Two different bit stream for recording and live streaming via 4G/3G

Default

Can set to default setting

Indicator

Power, record, snap, audio record

Battery capacity

2-piece replaceable battery, 2600mAh each, keep NON-4G device running for about 8h, keep 4G device running for about 4.6H

Charging time is about 4H

Backup battery

60mA (optional, keep device running during switch battery or battery run out)

Size

88.3*59.8*34.4mm

Wight

About 165g
