Body camera Home>Products>Body camera

AY-MB1208

Product Category:

Body camera

Product Figure:

  • Features
  • Technical parameters
  • Product Application

Ambarella S5L chipset

H.265 compression
Build-in 3500mAh battery
H.264(MP/HP Level 5.1)/H.265(MP Level 5.0)
4G GPS WIFI G-sensor, Support Onvif and Extra Camera
Video input: OS05A10


Model

AY-MB1208

OS

Chipset

Ambarella S5L

OS

Linux 4.9.110

Booting time

< 6 Seconds (From power on to recording)

Language

English/Chinese

Video

Video input

OS05A10

Video output

2 inch Full HD LCD screen

Recording Resolution

2560x1440,1920x1080,1280x720

Frame rate

1440p30,1080p60,1080p30,720p60,720p30

Compression

H.264(MP/HP Level 5.1)/H.265(MP Level 5.0)

Audio

Audio input

1x MIC input, optional external intercom audio input

External audio interface

2.5mm jack for headphone, microphone and PTT

Compression

PCM format (AAC optional)

Video process

Video resolution

2560x1440, 1920x1080, 1280x720

Photograph

1920x1080 8640x4752

Snap

Support snapping during recording(photo resolution same as recording video)

Storage

Built in 16GB TF card(optional for 32256GB)

Light

IR

Up to 10 Meters at 0 lux with Visible shape image

Flash light

help for view in night

Laser

lock image center or pointing

Lens

HOV

>120°

Alarm

SOS

SOS key press will be notificated on the platform (only for 4G/3G device)

COM port

USB

1x USB,for charging, communication with PC, connect external HD camera

3G/4G

built in 3G/4G module(FDD-LTE/WCDMA/GPRS)  (only for 4G/3G device)

wifi

Optional,support WIFI Client and AP mode

GPS

GPS

GPS/GLONASS(optional),location and speed can be used in local record and remote view, excellent signal quality with cold start <25 seconds

Firmware

Face Recogntion

Deep learning face recognition, huge local blacklist or cloud recognition (Optional )

Remote image function

Support online playback and downloading remotely (only for 4G/3G device)

Playback speed

Support from 1 to 128

Pre/post- recording

Maximum 20s pre-recording and post-recording

Dewarp

Support dewarp before encoding(>120 degree), support maximum 8X digital zoom

Record encryption

Support Record encryption, encrypted video can be only played in special player

Log

Record key operation, setting change, events, alarms and other information

Working condition

Temperature

 -30--60

Humidity

 40%80%

Time

synchronize date and time with GPS, internet, PC

Dual video stream

2 Independent Video Streams for Local Record and Remote View

Battery capacity

Option 1: 3500mAh for 1080p30 continuous recording upto 14h, for continuous 4G remote view up to 7.5h, Full charged within 3h

Option 2: 4200mAh for 1080p30 continuous recording upto 15h,for continuous 4G remote view up to 9h, Full charged within 3.5h;

Waterproof

IP68

Size

83.2*54.8*29.8mm

Wight

145g(without clip)
