Model number AY-MDC21G

Screen 3.0inch IPS Touch Screen

CPU MTK6582, 1.3Ghz, Quad Core

Storage Flash ROM4GB EMMC

RAM 512M LPDDR3

GPS external GPS antenna

Network Band WCDMA:2100(B1)

G-Sensor 3-axis G-Sensor

Loop Recording Support

Parking Monitor Support

Front CameraPS5220 Sensor; 1080P ; F=1.8; 6-glass lens; 140° wide angle
H.264 video code; Support Dual Camera video recording (Don't support auto reverse parking )

Back camera480P; 4 glass lens; USB digital rear camera

Standby power consumption 4MAH

Hotspot Support WIFI hotspot

Input/OutputSpeaker Build in speaker (Power: 8Ω/0.5W)

MIC Build in MIC-Phone Noise Reduction

TF card Support TF card, maximum 32GB

USB Mini USB 2.0

Key button Power button

RESET Support

powered by External power line power supply; power supply voltage 9V-25V

Temperature and humidity rangeTemperatureUsage: -30~+70°C

Storage: -35~+85°C

humidity Usage: 4%~90%RH

Storage: 40%RH

Product Size87mm x 71mm x 33mm

Package1x dash camera; 1x power cable; 1x rear camera kits , 1x GPS antenna, 1x user manual

Mobile App for Android/ Ios

Parking Monitor Support capture front and rear camera video and image

Real-time preview Support 1080p video live preview

GPS track history Support GPS logger path and video synchronous playback

Monitor and Alarm Support Message / photo alarm if collision happened when car parking

Video download Support Point-to-point video download to the phone, don't consume internet data

Share video to alburm Support car life
