| Function |
AY-MRK9908 |
|
| System |
Language |
English | Chinese | Russian | Korean | Portuguese | Turkish | Hebrew, and other languages supported. |
| Operation Interface |
Graphical User Interface (OSD menu) |
|
| Password Security |
2 Levels: Administrator & User |
|
| AI Algorithm |
DSM (AY-DMC921/938) |
Yawning Detection Eyes Closing Detection Smoking Detection Making Phone Calls Detection Distraction Detection Driver Absence Detection Camera Covered Detection Wearing Glasses Detection |
| ADAS (AY-AMC920) |
Lane Departure Warning Safe Distance Warning Froward Collision Warning Pedestrian Collision Warning |
|
| BSD（Optional） |
Support Blind Spot Detection cameras (2 channels) |
|
| Video |
Video Input |
Supports 4×30fps 1080P AHD + 8×30fps 4K IPC simultaneous input Option1: ‧2 channels 1080P AHD (DSM & ADAS) , and ‧2 channels 1080P/960P/720P AHD/960H/D1/CIF , and ‧8 channel IPC (4K/2K/1080P/720P) Option2: ‧4 channels 1080P/960P/720P AHD/960H/D1/CIF, and ‧8 channels IPC (4K/2K/1080P/720P) |
| Video Output |
‧3 Output Channels: ◦ CVBS via Front Panel 3.5mm Jack ◦ CVBS via 4PIN from the I/O cable ◦ VGA （1280*1024） |
|
| Video Display |
Supported split-screen layouts: 1/2/3/4/6/9/12 channels |
|
| Signal System |
PAL / NTSC |
|
| Image Compression |
H.264/H.265 Main profile |
|
| Audio |
Audio Input |
4 Channels |
| Audio Output |
2 Channels (Front Panel 3.5mm Jack, 1 in the 24pin connector) |
|
| Record Format |
Synchronized A/V recording |
|
| Recording & Storage |
Image Resolution |
CIF / HD1 / D1 / 960H / 720P/1080P options |
| Video Coding |
ISO14496-10 Industry Standard |
|
| Video Bit Rate |
CIF: 128Kbps ~ 1536Kbps |
|
| HD1/D1: 400Kbps ~ 2048Kbps |
||
| 960H: 400Kbps ~ 2048Kbps |
||
| 720P: 400Kbps ~ 4096Kbps |
||
| 1080P: 400Kbps ~ 4096Kbps |
||
| 8-level able (Level 1=Highest ~ Level 8=Lowest) |
||
| |
Audio Bit Rate |
40Kbps |
| Storage |
‧Primary Storage: ◦ 2.5" HDD (7mm~9mm, up to 2TB) ◦ or 2.5" SSD (up to 8TB) ‧Backup Storage: ◦ SD card slot (available on 3G/4G/WiFi models) |
|
| Alarm |
Alarm Input |
8 Channels, Select Trigger for either less than 1VDC or greater than 5VDC |
| Alarm Output |
1 Channel, 12V output |
|
| Communication Ports |
RS485 |
1× port (for PTZ control / data device) |
| RS232 |
2× ports (for data communication) |
|
| RJ45 Network |
8+1, 100M Ethernet, supports up to 4K IP cameras |
|
| Speed |
1 Channel（Optional, shared with the port IO /IN 8) |
|
| CAN Bus |
1 Channel（Optional, shared with the port IO /IN 6-7) |
|
| USB |
Front Panel: USB 2.0 (Type-A,firmware upgrade / data download / USB mouse) Rear Panel: USB 2.0 (Type-C) |
|
| Wireless Communication* |
4G/5G* |
Optional |
| Wi-Fi* |
Internal Wi-Fi 802.11b/g/n/ac optional |
|
| GPS* |
Internal Standard GPS* |
Internal GPS module. Real-time geographic coordinates, speed information |
| G-Sensor |
Internal G-Sensor |
Support an integrated 3 axis accelerometer (G-Sensor) and 3 axis gyroscope, to detect crash, harsh breaking, acceleration and cornering. |
| Software |
PC Playback |
A/V, GPS, Mapview, Speed, G-Sensor, etc. files available for playback on PC. Limited playback is also available on MDVR |
| IVMS |
Wireless (require Wi-Fi or cellular Option) real-time A/V monitoring, GPS, alarms, etc. |
|
| Software Upgrade |
Local or Remotely |
Upgrade through the front USB2.0 or remotely via IVMS platform |
| Voltage Input |
+8～+36V |
8～36VDC Please check operational voltage of vehicle prior to the installation of the MDVR and its accessories to prevent possible damage |
| Voltage Output |
12V |
12V（+/-0.2V），Max 3A |
| Video Input Resistance |
75Ω |
75Ω |
| Video Output Voltage |
2Vp-p |
2VP-P CVBS output analog signal, screen input requires 75Ω resistance |
| I / O port |
<1V |
Low voltage trigger |
| >5V |
High voltage trigger |
|
| Operation Temperature |
-40℃～80℃ |
Install in well ventilated area, protected from moisture, heat, dust and vibration |
| Dimensions |
192x184x61mm |
Including Security Cover 248x184x61mm |
